DIY Automatic Chicken Feeder

Dick Shuttleworth teaches you how to construct a homemade chicken feeder for your flock.

article image
Adobe Stock/antonivano

Build this DIY automatic chicken feeder. These chicken feeder plans include materials and step-by-step instructions to help you get started.

You can feed baby chicks out of flat troughs but, once they’re 6 to 8 weeks old, you’ll need an automatic feeder for them. One that holds about 100 pounds of mash is about right and as promised last issue here’s the detail on a simple, sturdy self-feeder that Dad designed years ago. One just like this handled many hundreds of chickens over a years-long period back on the farm in Indiana.

Most homesteads should already have most of the necessary materials kicking around the workshop or back shed. A couple of 5-inch hinges, short length of light chain, an old broomstick, some wire, a few nails and a small selection of 3/4-by-12-inch lumber are the major ingredients. The cutaway below shows you how they all go together.

Automatic Chicken Feeder Plans

The idea is, of course that the chickens jump on the platform to get the feed and by so doing (since the platform is supported so that it will rock up and down on either side), continually work more feed down to where they can get at it. If the mash was TOO easy for them to pick out of the feeding tray, however, they would waste it, so a feed saver wire is run down both sides of the eating trough.

Stretched about 1-1/2 inches inside the trough’s side and about the same distance above the bottom of the tray, these wires make eating just difficult enough to prevent a flock from pulling excess mash out of the feeder. The other critical dimensions of the feeder’s “shake down” mechanism are shown. Position the Platform Rocker Stops so that the Platform can only rock up and down about one inch on each side.
