DIY Rabbit Tractor

• • 1-by-4s
  • 1-1/4-inch screws for wooden frame
  • 1 sheet of plywood
  • 3/4-inch fencing staples
  • 2-by-3-inch welded wire mesh for bottom (use 1-by-2-inch welded wire if you’ll be raising small meat rabbits)
  • 1/2-inch hardware cloth for sides
  • 1 center-mounted wheel (2 wheels if using a side-by-side design)
  • 2-by-2s for handles
  • 3-inch screws for handles
  • Lightweight sheet metal for roof
  • 1/2-inch screws to attach roof

• Piano hinge
• Large knob

Tools

• Circular saw
• Hammer
• Battery-powered drill with screwdriver tip
• Wire-cutting pliers
• Tin snips
• Tape measure, straightedge, pencil

Cutting List

Plywood:

• Two 23-by-28-inch ends
• One 19-by-27-inch floor
• Two 19-by-23-inch sides
• One 5-by-28-inch front lip

1-by-4s:

• Six 29 1/2-inch pieces
• Four 24-inch pieces
• Three 22 1/4-inch pieces
• Two 4-by-4-inch pieces

Directions to Build This DIY Rabbit Tractor

1. For the top and bottom, build two 30-by-72-inch frames out of 1-by-4s. I salvaged my lumber from some large shipping pallets.
2. Attach the two frames together with 1-by-4-inch boards cut 30 inches long to form a box frame. I also put support boards across the top and bottom to sturdy up the structure.

3. Cut some plywood to the cutting list specifications to form a box at what will be the wheel end of the rabbit tractor. This will create a safe place for the rabbits to seek protection from the elements and sleep. To create a shade wall, cut another piece of plywood into a 23-by-28-inch rectangle to fasten to the opposite end of the rabbit tractor.

4. With staples, attach the 2-by-3-inch welded wire to the bottom and cut it down so that it’s long enough to wrap up over the ends. Do the same with the 1/2-inch hardware cloth for each side.

5. Raise the end with the solid-walled box a few inches off the ground and let it rest on blocks while you attach the wheel to the front of the rabbit tractor, wheelbarrow-style. You could do the same thing using two wheels, one on either side, for a wagon-style setup.
6. Add 2-by-2 wheelbarrow-style handles to either side of the rabbit tractor at the end opposite the wheel.
7. Cut a piece of sheet metal to size for the roof, and build a frame to fit using the 1-by-4 lumber.

8. Attach the metal to the wood frame with 1/2-inch screws and then attach the lid to the top of the rabbit tractor with a piano-style hinge.

9. Finish the tractor lid with a large knob as a handle.

I’m really pleased with the way my DIY hack turned out. I’ve been raising meat rabbits in the tractor for a while now, and they love the fresh patch of grass I give them twice daily. I love it because it’s easy to move and cuts way down on the feed I have to buy, and I’m able to raise healthy, happy rabbits.
